Description
Shaped molybdenum crucible is a kind of indispensability material in rare-earth smelting industry. Our company can produce various molybdenum crucibles, such as round mouth crucible, taper crucible, ellipse crucible and bottomless crucible. Also it can be produced according to the customers' requirements.
Features
1. The purity of shaped molybdenum crucible can reach as high as 99.95%;
2. Its impurity content is in accordance with GB/T3462-2007.
3. The appropriate working temperature of molybdenum crucibles is between 1400℃ to 1900℃.
Application
1. Shaped molybdenum crucible is mainly used in metallurgy industry and mechanism process industry.
2. More and more molybdenum crucibles are also used in crystalloid materials and other burgeoning high technology industry.
Parameters
| Shaped Molybdenum Crucible | Purity | Density | Diameter | Height |
| Forging | 99.95% | 10.1g/cm3 | 10mm-130mm | 10mm-200mm |
| Sintering | 99.95% | 9.8g/cm3 | 100mm-400mm | 50mm-500mm |
Packaging and Delivery
| Packaging | Wooden case with waterproof paper inner |
| Delivery | 10-25 days (according to your qty) |
Package and Inspection
Achemetal Furnace Co., Ltd owns a complete range of manufacturing equipments. We provide you with test data of surface roughness, density, roughness, ductility, flaw detection, dimensions and so on. We promise our molybdenum crucibles are under process of vacuum annealing furnace, ultrasonic cleaning and vacuum packing before delivery.
Owning lathes, milling machines, EDM and CNC technology, Achemetal Furnace Co., Ltd is a professional manufacturer and supplier of shaped molybdenum crucibles in China. We also specialize in producing tungsten crucibles for quartz melting or vacuum coating, tungsten and molybdenum parts for ion implantation as well as tungsten and molybdenum connection parts with high purity and excellent mach inability. All of our products are made in accordance with the standard of ISO9001. Above 60% of our products are exported to more than ten countries and areas, such as USA, Germany, Japan, Russia, South Korea, etc. Our shaped molybdenum crucibles have been highly recognized by customers for their excellent quality and accuracy.
