Application
1. Tungsten plates are used for producing tungsten electrodes, heating elements, heat shields, sintering trays, sintering boats, stacking sheets, base plates, sputtering targets, crucibles in electronic and vacuum applications.
2. Rolled tungsten plate is basically used in the technology of coating manufacturing and chemical vapor deposition (CVD) and physical vapor deposition (PVD) of thin film, including heat and electron beam evaporation, low temperature organic evaporation, atomic layer deposition (ALD), specific application of metal organic chemical vapor deposition (MOCVD).
3. Tungsten plates are widely used in rotating anode X ray tube, heating elements in high temperature furnace, reflection shield, sapphire growth furnace, high temperature tape, insulation screen, vacuum coating equipment and the shield of high temperature resistance ship.
Features
1. Rolled tungsten plate has the highest melting point and boiling point among all metals.
2. Three production methods include hot rolling process, warm rolling process and the cold rolling process. The production process involves stamping, spinning and drawing.
3. It is of high density, internal structure stability, resistance to high temperature.
4. We can produce tungsten plates with matte surface or glossy surface according to different materials' thickness, width and rolling process5; The purity can reach 99.97% and density 18.8-19.1g/cm3.
5. This plate from Achemetal is under vacuum annealing and leveling before delivery.
6. The rolled tungsten plate is approved by ASTM B 386-2003 and GB 3876-2007 and GB 3877-2006.
7. We can produce tungsten plates are with matte surface or glossy surface according to different materials' thickness, width and rolling process.
Parameters
| Thickness (mm) | Width (mm) | Length (mm) |
| 1.5-2.0 | 150 | 200 |
| 2.0-3.0 | 200 | 250 |
| 3.0-4.0 | 250 | 600 |
| 4.0-6.0 | 300 | 600 |
| 6.0-8.0 | 300 | 600 |
| 8.0-10.0 | 300 | 750 |
| 10.0-14.0 | 200 | 650 |
| 14.0 - | 250 | 500 |
Parameters of Tungsten Square Plate
| Thickness (mm) | Width (mm) | Length (mm) |
| 1.0-5.0 | 500 | 500 |
| 6.0-10.0 | 400 | 400 |
| 10.0-14.0 | 350 | 350 |
| 14.0- | 300 | 300 |
Our company can also provide tungsten plates according to customers' requirements.
Package and Inspection
We offer material composition sheet and examination report which include density, flaw detection, dimensions and so on. Our products are packed in plywood case with expanded plastic. Each piece is separated by water proof paper.
We are a professional manufacturer of rolled tungsten plates in China. Owning two hot rolling machine and five cold rolling machines, Achemetal Furnace Co., Ltd. can supply vacuum annealed tungsten and molybdenum foil, sheets, plates, discs, squares and ribbons with high density and excellent mach inability. We output products with smooth surface, no double skin, no stratification, no crack and no impurity. In addition to tungsten plate, we also produce other rolled tungsten and molybdenum products, such as tungsten and molybdenum sheets, Mo-La sheets, tungsten and molybdenum foils, tungsten and molybdenum discs, etc. All of our tungsten plates are made in accordance with the standard of ISO9001.
